| Specifications | Single Phase | 3 Phase |
| Electrical Output | 220 - 240 VAC | 380 - 400 VAC |
| Frequency | 50/60 Hz | 50/60 Hz |
| Max. charging Capacity | 7.6 kW | 22 kW |
| 1 Hour Charge (Est. range per hour) | 25 miles/40 km | 70 miles/110 km |
| Charging Time For 100 km | 2.5 hours | 0.9 hour |
| Timer Function | From 1 to 12 hours | From 1 to 12 hours |
| Electrical Protection | Surge protection, GFCI protection, UVP, OVP, OCP, OTP Type A + DC 6mA | Surge protection, GFCI protection, UVP, OVP, OCP, OTP Type A + DC 6mA |
| Residual Current Protection | Type A + DC 6mA | Type A + DC 6mA |
| IP Rating | IP65(control box) connector IP54 | IP65(control box) connector IP54 |
| Operating Temperature | -30°C to 50°C | -30°C to 50°C |
| User Interface | OLED display touch button, RFID | OLED display touch button, RFID |
| Safety Standard | IEC 62196 - 2, IEC 61851 - 1 | IEC 62196 - 2, IEC 61851 - 1 |
| Dimensions | 330 x 193 x 90mm | 330 x 193 x 90mm |
| Net Weight | 5.5kg including cable & charging connector | 5.5kg including cable & charging connector |
| Gross Weight | 8.0kg | 8.0kg |
